The Orange Pi Prime development board has introduced Bluetooth support in the Orange Pi family. The AMPAK AP6212 chipset supports IEEE 802.11 b/g/n WiFi and Bluetooth 4.0. As an added bonus, it incorporates a radio receiver in the FM base. It will replace the Orange Pi PC 2 very favorably. On the other hand, it does not have any memory storage eMMC and no expansion slot is provided on the card. It will be enough to make run the distribution Armbian, Ubuntu, Android on an SD card.

Follow this tutorial to install Armbian without a screen or keyboard using a single FTDI cable from another computer!

Technical specifications for Orange Pi Prime

Changes from the Orange Pi PC 2 are marked in bold.

  • SoC: Allwinner H5 quad core Cortex A53 integrating the GPU ARM Mali-450MP4
  • Memory: 2GB DDR3 shared with the GPU
  • Storage: Micro SD card reader compatible up to 64GB
  • Video output: HDMI 1.4 compatible with CEC, AV port
  • Audio I/O: HDMI, microphone on the card
  • Connectivity:
    • Gigabit Ethernet
    • WiFi 802.11 b/g/n
    • Bluetooth 4.0 with u.FL antenna (IPEX connector on the card shared with WiFi)
  • USB
    • 3x USB 2.0
    • 1x micro USB OTG port
  • Camera: Compatible MIPI CSI interface up to 5 MP
  • Connector: 40-pin Raspberry Pi compatible (check the availability of libraries for your languages)
  • Debugging: 3x UART pins for serial console
  • Misc
    • IR Receiver
    • Power and reset buttons
    • Led: power on and status
  • Power supply
    • 5V/2A via barrel jack
    • micro USB port
  • Dimensions: 98 x 60 mm (85 x 55 mm for the Orange Pi PC 2)
  • Weight: 48 grams (38 grams for Orange Pi PC 2)

Technical Documentation and Distributions

Compare Orange Pi Prime with other models

No posts for this criteria.

Best Internet Deals

History of the best deals on Aliexpress

Orange Pi Prime: Development Board H5 Quad-core Support linux and android Beyond Raspberry Pi 2 Wholesale is available

Price: $35.90
as of 4 June 2020 3 h 00 min
Buy Now
Aliexpress.com
Wait For A Price Drop

Price History

Statistics

Current Price $35.904 June 2020
Highest Price$35.9012 December 2019
Lowest Price$35.9012 December 2019
Since 12 December 2019

Last price changes

$35.9012 December 2019

Packs and accessories for Orange Pi Prime

Click to rate this post!
[Total: 0 Average: 0]

Specification: #Deal: Orange Pi Prime 64bits, A64, 2GB DDR3, WiFi + Bluetooth 4.0

Memory Capacity (GB)

Processor Brand

Brand Name

Intergrated Feature

, ,

Interface

, ,

Demo Board Type

Model Number

Orange Pi Prime

is it customized

Operating Temperature

Application

, ,

Supply Voltage

CPU

H5 Quad-core Cortex-A53

Memory (SDRAM)

2GB DDR3 (shared with GPU)

Power Supply

DCIN, cant power through micro USB(OTG)
